| DE1848-V2@P | ||||||||
| Module | ||||||||
| Controller number | 1 | |||||||
| Power Consumption | 640W | |||||||
| Power Supply | 100V – 127V/200V – 240V AC;60Hz/50Hz | |||||||
| Weight | Fully loaded:<= 68kg | |||||||
| Dimension | 178mmX 482mm X801mm Note:for standard cabinet with 1000mm depth or above | |||||||
| Authentication certificate | CE, FCC, CB,RoHS, WEEE | |||||||
| Operating temperature | 5°C ~ 40°C / 41°F ~ 104°F | |||||||
| Interface | ||||||||
| HDD slot | 48 | |||||||
| Serial port | 1 | |||||||
| Back-end Expansion Interface | 2-port 4x12GbpsMini SAS HD | |||||||
| Class | Date | Title | Language | Type | Preview | Download |
| Datasheet | 2025/12/6 6:39:11 | UNV DE1848-V2@P DE1848-V2@P.pdf | English | Preview | Download A > |
| Class | Date | Title | Type | Download |
| HD Image | 2026/5/31 3:23:40 | DE1848-V2@P_HD_Image_1.png | png | Download |
| HD Image | 2026/5/31 3:23:40 | DE1848-V2@P_HD_Image_2.png | png | Download |
| HD Image | 2026/5/31 3:23:40 | DE1848-V2@P_HD_Image_3.png | png | Download |
| Class | Date | Title | Download |
| Dimensions | 2026/5/31 3:23:40 | DE1848-V2@P_Dimensions_1.png | Download |
