Constant closing speed at various ambient temperatures, adjustable closing torque, closing speed and latching speed.
Imported anti-freeze hydraulic fluid provides the product with a 2-year guarantee.
Two-section speed adjustment, flexible installation on either left or right door leaf.
90° stop function: The door can stop and stay at 90° opening angle (please specify the function when ordering).
Continuously adjustable closing speed in the range of 3s to 40s from 90°.
Backcheck function: When the door is opened over 65°, the door closer can produce a certain damping force to prevent the door from opening too fast with excessive force which could result in door slamming to the wall.
Parameter | Description | ||
Model | OEP-K13-65 | OEP-K14-85 | |
Closing force | EN3 | EN4 | |
Maximum opening angle | 180° | ||
Door width support | 950mm | 1100mm | |
Door weight support | 65kg | 85kg | |
MCBF | 1 million | ||
Operating environment | Operating temperature: -30°C to 60°C, operating humidity: ≤95% | ||
Dimensions (L×W×H) | 180*40*57mm | 205*42*64mm | |
Attestation | CE/FCC/ROHS |
