Automatic door opening for unobstructed access in case of power failure.
Electric leakage protection for pedestrian safety.
LED indicates the passing direction and passing status, preventing reverse access.
Pedestals of 1.0mm thick on the side and 1.2mm thick on the top, sturdy and reliable, simple and elegant.
IP54.
Anti-rush: Remains closed unless an opening signal is received.
Anti-impact: Able to withstand illegal external impacts for controller protection.
Automatic reset: Automatically cancels the passing permission if a person does not pass through within the valid passing duration.
STC CPU chip ensures long lifetime and high stability.
MCBF 3 million times.
With face recognition terminals connected, multiple authentication modes are available, such as face allowlist (1:N), face and IC card, and card.
Parameter | Description |
Throughput | 20 to 30 persons per minute |
Fire alarm linkage | Auto door opening in case of power failure |
LED color | Red/Green |
Pedestal material | 1.0mm thick on the side, 1.2mm thick on the top |
MCBF | 3 million times |
Power | AC100-240V, 50Hz to 60Hz |
Power consumption | 40W |
Weight | 35KG |
Dimensions (L×W×H) | 980mm*430mm*320mm |
Lane width | 550mm |
Operating temperature | -20°C to +60°C (temperature control module required) |
Relative humidity | 5% to 80% |
Interface | IO input*2、IO output *2 、 RS232*1 |
Ingress protection | IP54 |
Barrier material | Stainless steel round rod |
Barrier fall mode | Auto fall after power failure, manual lift after power on, auto reset after impacts |
