Model | UAC-B124-AF28LM | UAC-B124-AF40LM |
Sensor | ||
Pixel | 4MP | |
Size | 1/3" | |
Minimum illumination | 0.005 lux (F1.6, AGC ON) 0 lux (IR on) | |
Lens | ||
Lens | 2.8mm | 4.0mm |
Lens mount | M12 | |
Angle of view | H: 97.7° V: 54.9° D: 111.9° | H: 81.1° V: 41.0° D: 94.4° |
Illuminator | ||
Illuminator | Two IR illuminators | |
Illumination distance | 40m | |
Lifetime | ≥60,000 hours | |
Video | ||
Resolution | 4MP: 2560(H) × 1440(V) 1080P: 1920(H)×1080(V) | |
Frame rate | TVI/AHD/CVI: 4MP@25fps (default), 4MP@30fps,1080P@25fps, 1080P@30fps CVBS: PAL, NTSC | |
Shutter time | PAL: 1/25s-1/50000s NTSC: 1/30s–1/50000s | |
Image | ||
Exposure mode | Four modes: Global (default), BLC, HLC, DWDR | |
Day/Night | Three modes: Auto (default), Day, Night | |
Digital noise reduction | 2D | |
White balance | Two modes: Auto (default), Manual | |
WDR | DWDR | |
Smart IR | Support | |
Flip | Supports 180° horizontal flip, 180° vertical flip | |
Audio | ||
Microphone | Built-in Mic | |
Camera audio | TVI: 4MP@25fps, 4MP@30fps,1080P@25fps, 1080P@30fps CVI: 4MP@25fps, 4MP@30fps | |
Interface | ||
Power | 5.5mm power interface | |
Video output | BNC, supports TVI/AHD/CVI/CVBS | |
Operating environment | ||
Temperature | -30°C to 60°C (-22°F to 140°F) | |
Humidity | ≤95% (RH, non-condensing) | |
Surge protection | 4kV | |
Ingress protection | IP67 | |
General | ||
Power | DC 12V (±25%), with reverse polarity protection, Max 3.5W | |
Mount | 3D bracket supplied, surface mount (default), optional backbox, pole mount bracket | |
Dimensions | 154mm*66mm*66mm (L*W*H) | |
Material | Metal+Plastic | |
Weight | 240g (0.53lb) | |
Certification | CE, FCC, UL |
