| PKC17C0@6-C-LP | ||||||||
| Camera | ||||||||
| Sensor | 1/1.7" 12MP CMOS | |||||||
| Focal length | 1.8mm | |||||||
| Shutter | 1/100000 to 1/25s | |||||||
| Minimum illumination | 0.03lux | |||||||
| Lens type | Fixed-focal lens | |||||||
| Iris | F2.0 | |||||||
| FOV | 180° | |||||||
| Display Parameters | ||||||||
| Resolution | Main stream: 3840*2160; Sub stream: 3280*2464, 2000*2000; Third stream: 720*576 (D1), 352*288 (CIF) | |||||||
| Image | ||||||||
| Frame rate | 20, 18, 16, 15, 12, 10, 8, 6, 5, 4, 3, 2, 1 | |||||||
| Video compression | H.264 (default), H.265 | |||||||
| ROI | Support, up to 8 areas | |||||||
| Video OSD | Supports custom OSD on live view and image | |||||||
| Image OSD | Supports custom OSD on live view and image | |||||||
| Privacy mask | Support, up to 4 areas | |||||||
| Interface | ||||||||
| Network interface | 1 x 1000M/100M/10M adaptive Ethernet copper port | |||||||
| Serial port | 1 xRS485 | |||||||
| Boolean output | 1 x alarm output | |||||||
| Boolean input | 2 x alarm input | |||||||
| Audio interface | 1 x audio output, 1 x audio input | |||||||
| Built-in mic | Support | |||||||
| Built-in speaker | Support | |||||||
| BNC | Support | |||||||
| Service Config | ||||||||
| Third-party server | Two photo servers via HTTP, VIID, and FTP protocols; MQTT server via MQTT protocol | |||||||
| Smart | ||||||||
| Parking space detection | Supports detecting 6 parking spaces and recognizing 6 license plates | |||||||
| Parking space detection rate | 99% | |||||||
| Structure | ||||||||
| Indicator | 7-color LED indicator, displays the parking space status | |||||||
| Mount method | Adapter panel | |||||||
| General | ||||||||
| Power supply | DC 12V ±25%, PoE (802.3at) | |||||||
| Weight | 690g | |||||||
| Ingress protection | IP67 | |||||||
