Front panel: Aluminum alloy
Supports batch configuration
Supports intercom calls to associated indoor units or APPs
Support monitoring function, security alarm, tamper alarm
Support Wi-Fi
Built-in IC card reader
Parameter | Description |
Power | DC 12V±25% input;IEEE802.3af, Standard PoE |
Card capacity | 10000 |
Operation system | Linux |
Supplement light | IR light(Adaptive infrared compensation) |
WDR | Support |
FOV | Horizontal:124.3° Vertical:67.5° Diagonal:147.2° |
Power consumption | <10W |
Volume adjustment | Adjustable |
Audio quality | Noise suppression,echo cancellation and AGC |
Audio input | 1 built-in omnidirectional microphone |
Audio output | 1 built-in speaker |
Audio compression standard | PCM,G711,MP3 |
Audio compression bitrate | 128Kbps |
Protocol | UNV private protocol |
Button | 1 physical button |
Protection level | IP65 (Apply waterproof glue to the gap between the device and the wall. For more information, see the quick guide.) IK08 |
Weight | 0.267Kg |
Linked indoor station capacity | 20 |
Mount method | Wall mounted, flush installation |
Interface | Power *1, network port *1, WIFI, RS485, door lock interface *2, IO input *4 |
Network | 100Mbps network port, supports IEEE802.3af PoE power supply |
Dimensions (L×H×W) | 79mm×171mm×34mm |
Operating environment | ﹣30℃~﹢60℃,10%~90%, non-condensing, outdoor |
