Industrial-grade panel, highly reliable integrated structure design, continuous stable operation.
Direct-lit LED backlight provides high brightness uniformity without border shadows.
Ultra-narrow 3.5 mm seam.
Supports white balance adjustment, delivering delicate and colorful images.
Wide 178° viewing angles.
Built-in image splicing function(work with splitter).
Support anti-burn technology, landscape and portrait installation.
Supports delayed boot after power on.
Advanced direct-lit local dimming technology with low power consumption, saving energy.
Metal case protects the unit from interference of radiation, magnetic fields, and strong electric fields.
Support remote control and RS232 hoop control.
Model | MW-A46-B1-C |
Panel | |
Panel size | 46 inches |
Resolution | 1080P |
Physical seam (mm) | 3.5 |
Color support | 16.7M |
Brightness (cd/m²) | 500 |
Contrast ratio | 1200:1 |
Response time (ms) | 8 |
Viewing angle | Horizontal 178°, Vertical 178° |
Interface | |
Video input | 1*HDMI、1*DVI、1*VGA |
Other interfaces | 1*USB 2.0、2*RS232、1*IR interface |
OSD | |
Multi- Language | English、Simplified Chinese |
General | |
Power supply | AC 100 to 240V, 50/60Hz |
Product dimensions (W*H*D)(mm) | 1022.38*576.97*82.30 |
Power consumption (W) | 125 |
Lifetime (h) | 50000 |
Weight (kg) | Net Weight: 12.65 Gross weight (1 display included): 16.1 Gross weight (2 displays included): 31.3 |
Operating temperature | 0℃ to 40℃ |
Operating humidity | 20% to 90% (non-condensing) |
Storage temperature | -20℃ to 60℃ |
Storage humidity | 10% to 90% (non-condensing) |
Accessory | |
Standard | 1*Remote Control、1*Power Cable、1* Ground Wire、1* Infrared Extension Cable、 1*Network Cable |
