Industrial-grade panel, highly reliable integrated structure design, continuous stable operation.
Direct-lit LED backlight provides high brightness uniformity without border shadows.
Ultra-narrow 3.5 mm seam.
Supports white balance adjustment, delivering delicate and colorful images.
Wide 178° viewing angles.
Built-in image splicing function(work with splitter).
Support anti-burn technology, landscape and portrait installation.
Supports delayed boot after power on.
Advanced direct-lit local dimming technology with low power consumption, saving energy.
Metal case protects the unit from interference of radiation, magnetic fields, and strong electric fields.
Model | MW-A55-B1-C |
Panel | |
Panel size | 55 inches |
Resolution | 1080P |
Physical seam (mm) | 3.5 |
Color support | 16.7M |
Brightness (cd/m²) | 500 |
Contrast ratio | 1200:1 |
Response time (ms) | 8 |
Viewing angle (H/V) | 178°/178° |
Interface | |
Video input | DVI × 1, HDMI × 1, VGA × 1 |
Other interfaces | USB × 1, RS232 × 2, 3.5mm IR interface × 1, power on/off button × 1 |
General | |
Power supply | AC 100 to 240V, 50/60Hz |
Product dimensions (W×H×D)(mm) | 1213.50 × 684.30 × 88.99 |
Power consumption (W) | 180 |
Lifetime (h) | 50000 |
Weight (kg) | 17.5 |
Case color | Black |
Operating temperature | 0℃ to 40℃ |
Operating humidity | 20% to 90% (non-condensing) |
