Supports video stream based face detection and face comparison, monitoring with 100,000 face images.
Supports video stream based behavior analysis, and provides no helmet detection, no chef hat detection, no work clothes detection, smoking detection, smoke and fire detection, calling detection, no mask detection, and rat detection.
Can connect 4/8-channel Onvif or RTSP compliant third-party IP cameras.
Two 10M/100M/1000M network interfaces (RJ45).
Supports browser-based access and control.
Supports custom RESTful API and reporting real-time data to a specified server.
| Model | ECS-5004@A1 | ECS-5004@A1-HD | ECS-5008@A1 | ECS-5008@A1-HD | |
| IP video input | 4-ch | 8-ch | |||
| Decoding capability | 4 x 8MP@30 (1080P is recommended) | 8 x 8MP@30 (1080P is recommended) | |||
| Incoming bandwidth | 64Mbps | ||||
| Outgoing bandwidth | 64Mbps | ||||
| Smart | |||||
| Face library capacity | 128 face libraries, total 100,000 face images | ||||
| Video stream based behavior analysis | 4-ch (cannot be enabled simultaneously with face recognition) | 8-ch (cannot be enabled simultaneously with face recognition) | |||
| Behavior analysis type | No helmet detection, no chef hat detection, no work clothes detection, smoking detection, smoke and fire detection, calling detection, no mask detection, and rat detection. | ||||
| Snapshot storage | Max 50,000 records | ||||
| Hard Disk | NA | Including 2.5” 1TB HDD | NA | Including 2.5” 1TB HDD | |
| External interface | Network interface | 2 RJ45 10M/100M/1000M self-adaptive Ethernet interfaces | |||
| USB interface | 2 x USB3.0 | ||||
| Serial interface | 1 x RS485 (phoenix connector) | ||||
| Alarm in | 2-ch | ||||
| Alarm out | 1-ch | ||||
| General | Power supply | 12V/3A Power Consumption: ≤24 W (without HDD) | 12V/3A Power Consumption: ≤36 W (with HDD) | 12V/3A Power Consumption: ≤24 W (without HDD) | 12V/3A Power Consumption: ≤36 W (with HDD) |
| Working Environment | -20°C ~ + 60°C (-4°F ~ +140°F), Humidity ≤ 95% RH (non-condensing) | ||||
| Weight | ≤1kg (2.20lb) (without HDD) | ≤1.15kg (2.54lb) (with HDD) | ≤1kg (2.20lb) (without HDD) | ≤1.15kg (2.54lb) (with HDD) | |
| Dimensions | 181.0mm(W) × 150.0mm(D) ×36.0mm(H) | ||||
