| | UAC-B112-F28 | UAC-B112-F40 |
| Camera |
| Max Resolution | 2 MP |
| Sensor Size | 1/3.0" CMOS |
| Min. Illumination | 0.02 lux (F2.0, AGC ON) 0 lux (IR on) |
| Lens |
| Focus | 2.8 mm | 4.0 mm |
| Lens Mount | M12 |
| Angle of View (H) | 90.5° | 80.2° |
| Angle of View (V) | 49.6° | 40.7° |
| Angle of View (D) | 109.5° | 90.5° |
| Illuminator |
| Illuminator Number | One IR illuminator |
| Illumination Distance | 20m |
| Lifetime | ≥ 60000 hours |
| Video |
| Resolution | 1080P: 1920(H)×1080(V) 720P: 1280(H) ×720(V) |
| Frame Rate | TVI/AHD/CVI: 1080P@25fps(default), 1080P@30fps; 720P@25fps, 720P@30fps CVBS: PAL, NTSC |
| Shutter Time | PAL: 1/25s-1/50000s, NTSC: 1/30s-1/50000s |
| Image |
| Exposure Mode | Four modes: Global (default), BLC, HLC, DWDR |
| Day/Night | Three modes: Auto (default), Day, Night |
| Digital Noise Reduction | 2D |
| White Balance | Two modes: Auto (default), Manual |
| WDR | DWDR |
| Smart IR | Support |
| Flip | Supports 180°horizontal flip, 180°vertical flip |
| Interface |
| Power Interface | 5.5 mm Power Interface |
| Video Output | BNC, supports TVI/AHD/CVI/CVBS |
| Operating Environment |
| Temperature | -30°C to 60°C (-22°F to 140°F) |
| Humidity | ≤ 95% RH (non-condensing) |
| Surge Protection | 4 KV for power, 4 KV for video output interfaces |
| General |
| Power | DC 12 V ± 25% |
| Power Consumption | MAX 2.88W |
| Mount | Corner Mount, Pole Mount |
| Dimensions | 142mm*63mm*65mm (L*W*H) |
| Material | Plastic |
| Weight | 135g(0.30lb) |
| OSD Menu Language | 11 Languages: English, German, Spanish (Latin America), French, Italian, Japanese, Korean, Polish, Portuguese (Brazil), Russian, Turkish |
| Certification |
| EMC | CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035), FCC (FCC 47 CFR part15 B) |
| Safety | CE-LVD (EN 62368-1) |
| Environment | CE-RoHS (2011/65/EU; (EU) 2015/863); WEEE (2012/19/EU) |
| Protection | IP67 (IEC 60529) |
