Support Ultra 265/H.265/H.264 video formats
32/64 channel input
Support mainstream cameras of ONVIF conformance(Profile S, Profile G, Profile T) and RTSP protocols
Support 2 HDMI and 2 VGA. VGA1 and HDMI1 simultaneous output, VGA2 and HDMI2 simultaneous output. VGA1/HDMI1 and VGA2/HDMI2 independent output
Up to 32 Megapixels resolution recording
Support N+1 Hot spare
Support HDD hot swap with RAID 0, 1, 5, 6, 10 storage scheme configurable
Redundant power supply optional
ANR technology to enhance the storage reliability when the network is disconnected
Support cloud upgrade
Decoding | Description |
Decoding Format | Ultra 265,H.265,H.264 |
Decoding Capability | NVR508‑32E‑R‑IQ:Smart Off:2 x 32MP@30, 4 x 16MP@30, 5 x 12MP@30, 8 x 4K@30, 10 x 6MP@30, 12 x 5MP@30, 16 x 4MP@30, 20 x 3MP@30, 32 x 1080P@30 Smart On:1 x 32MP@30, 3 x 16MP@30, 4 x 12MP@30, 6 x 4K@30, 8 x 6MP@30, 9 x 5MP@30, 12 x 4MP@30, 16 x 3MP@30, 24 x 1080P@30, 32 x 720P@30 NVR508‑64E‑R‑IQ:Smart Off:2 x 32MP@30, 4 x 16MP@30, 5 x 12MP@30, 8 x 4K@30, 10 x 6MP@30, 12 x 5MP@30, 16 x 4MP@30, 20 x 3MP@30, 32 x 1080P@30, 64 x 720P@30 Smart On:1 x 32MP@30, 3 x 16MP@30, 4 x 12MP@30, 6 x 4K@30, 8 x 6MP@30, 9 x 5MP@30, 12 x 4MP@30, 16 x 3MP@30, 24 x 1080P@30, 48 x 720P@30 |
Audio Compression | G.711A,G.711U |
Network | Description |
Incoming Bandwidth | Smart Off:384Mbps Smart On:200Mbps |
Outgoing Bandwidth | Smart Off:384Mbps Smart On:200Mbps |
Remote Users | 128 |
Protocols | TCP/IP;P2P;NTP;DHCP;PPPoE;HTTP;HTTPS;DNS;DDNS;SNMP;SMTP;NFS;RTSP;802.1x;IPV6 |
Browser(Plugin) | Windows:IE(IE10/11),Firefox (version 52.0 and above),Chrome(version 45 and above),Edge(version 79 and above) |
Video/Audio Input | Description |
IP Video Input | NVR508‑32E‑R‑IQ:32‑ch NVR508‑64E‑R‑IQ:64‑ch |
RCA Audio Input | 1‑ch |
Video/Audio Output | Description |
HDMI Output | HDMI:4K(3840x2160)/60Hz, 4K(3840x2160)/30Hz, 1920x1080p/60Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
VGA Output | VGA:1920x1080p/60Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
RCA Audio Output | 2‑ch |
Liveview Display | NVR508‑32E‑R‑IQ:1/4/6/8/9/16/25/32 NVR508‑64E‑R‑IQ:1/4/6/8/9/16/25/36/64 |
Corridor Mode Screen | 3/4/5/7/9/10/12/16/32 |
Two-way Audio | Description |
Two-way Audio | 1‑ch,RCA(Using the audio input and output) |
Snapshot | Description |
FTP/Schedule/Event Snapshot | 16‑ch snapshot,up to 4K resolution |
Recording | Description |
Recording Resolution | 32MP/16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/D1/2CIF/CIF |
Smart | Description |
VCA Detection by IPC | Vehicle Detection;SIP(Intrusion Detection,Cross Line Detection,Enter Area,Leave Area);Ultra Motion Detection(UMD);Temperature Detection(Fire Detection,Smoking Detection,Temperature Measurement,Smoke and Fire Detection);People Counting(People Flow Counting,Crowd Density Monitoring);Video Metadata;Traffic Monitoring |
Smart by NVR | Smart Intrusion Prevention (SIP);Ultra Motion Detection(UMD) |
VCA Search | Motor Vehicle Search;Non‑Motor Vehicle Search;Human Body Search;General Search;People Counting Report;Heat Map |
Smart by IPC | All channels (up to 16 images/s in total) Vehicle Detection,Temperature Detection,SIP,UMD,Video Metadata,Traffic Monitoring |
Vehicle Picture Library | Up to 5 vehicle picture libraries,with up to 25,000 vehicle pictures in total |
SIP by NVR | 8‑ch |
UMD by NVR | 16‑ch |
Capacity of Snapshot Records | 2 millions records for vehicle snapshot;2 millions records for SIP;2 millions records for video Metadata |
Alarm | Description |
General Alarm | Defocus Detection;Scene Change Detection;Object Left Behind;Object Removed;Auto Tracking;Motion Detection;Tampering;Human Body Detection;Video Loss;Alarm Input;Audio Detection |
Alert Alarm | IP Conflict;Network Disconnected;Disk Offline;Disk Abnormal;Illegal Access;Hard Disk Space Low;Hard Disk Full;Recording/Snapshot Abnormal;Array Damaged;Array Degraded |
GUI Language | Description |
GUI Language | 38 languages: Simplified Chinese, Traditional Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian |
Hard Disk | Description |
SATA | 8 SATA Interfaces |
Capacity | Up to 16TB for each HDD(The maximum HDD capacity varies with environment temperature) |
Disk Group | Support |
Redundant Storage | Support |
Disk Array Type | RAID 0,1,5,6,10 |
Hot Swap | Support |
External Interface | Description |
Network Interface | 2 RJ45 10M/100M/1000M self‑adaptive Ethernet Interface |
USB | Front panel: 2 x USB2.0;Rear panel: 2 x USB3.0 |
RS485 | 1 |
RS232 | 1 |
Alarm In | 16‑ch |
Alarm Out | 10‑ch |
eSATA | 1 |
Power Output | 12V |
Power Supply | AC 100~240V |
Redundant Power Supply | Support |
Working Environment | Description |
Working Temperature | ‑10°C ~ + 50°C (+14°F ~ +122°F) |
Working Humidity | ≤ 90% RH (non‑condensing) |
Power Consumption (without HDD) | ≤ 20W |
Dimensions | Description |
Weight (without HDD) | ≤ 6.5Kg (14.3lb) |
Height | 2U |
Dimensions | 443mm × 448mm × 93mm (17.4"×17.6"×3.7") |
Certification | Description |
Certification | CE, FCC, UL, RoHS, WEEE |
CE | EN 55032, EN 61000‑3‑3, EN IEC 61000‑3‑2, EN 55035 |
FCC | Part15 Subpart B |
