Sistem Manajemen
Support Ultra 265/H.265/H.264 video formats
128/256-channel input
Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile C, Profile Q, Profile A, Profile T
Support 2-ch HDMI, 1-ch VGA, HDMI at up to 4K(3840x2160) resolution
HDMI1, HDMI2 and VGA independent outputs provided
Up to 12 Megapixels resolution recording
Redundant power supply optional
Support HDD hot swap with RAID 0, 1, 5, 6, 10, 50, 60 storage scheme configurable
24 SATA HDDs, up to 16TB for each HDD
Support 2 miniSAS Interfaces
Support 12V power output
ANR technology to enhance the storage reliability when the network is disconnected
Support cloud upgrade
Support N+1 Hot spare
| Decoding | Description |
| Decoding Format | Ultra 265,H.265,H.264 |
| Decoding Capability | 3 x 12MP@30, 5 x 4K@30, 20 x 1080P@30, 24 x 1080P@25, 40 x 960P@25, 45 x 720P@30, 54 x 720P@25, 96 x D1 |
| Audio Compression | G.711A,G.711U |
| Network | Description |
| Incoming Bandwidth | 768Mbps |
| Outgoing Bandwidth | 768Mbps |
| Remote Users | 128 |
| Protocols | TCP/IP & P2P & UPnP & NTP & DHCP & PPPoE & HTTP & HTTPS & DNS & DDNS & SNMP & SMTP & NFS & RTSP & 802.1x & IPV6 |
| Browser(Plugin) | Windows:IE(IE10/11),Firefox (version 52.0 and above),Chrome(version 45 and above),Edge(version 79 and above) |
| Video/Audio Input | Description |
| IP Video Input | NVR824-128-R-IX-8G:128-ch NVR824-256-R-IX-16G:256-ch |
| RCA Audio Input | 1-ch |
| Video/Audio Output | Description |
| HDMI Output | HDMI1/HDMI2:4K(3840x2160)/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| VGA Output | VGA:1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| RCA Audio Output | 1-ch |
| Liveview Display | VGA:1/4/6/8/9/16/25/36, HDMI1/HDMI2:1/4/6/8/9/16/25/36/64 |
| Corridor Mode Screen | 3/4/5/7/9/10/12/16/32 |
| Two-way Audio | Description |
| Two-way Audio | 1-ch,RCA(Using the audio input and output) |
| Snapshot | Description |
| FTP/Schedule/Event Snapshot | 128-ch snapshot, up to 4K resolution |
| Recording | Description |
| Recording Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/D1/2CIF/CIF |
| Synchronous Playback in Local | 16-ch |
| Smart | Description |
| VCA Detection by IPC | Vehicle Detection & SIP(Intrusion Detection,Cross Line Detection,Enter Area,Leave Area) & Ultra Motion Detection(UMD) & Temperature Detection(Fire Detection,Smoking Detection,Temperature Measurement,Smoke and Fire Detection) & People Counting(People Flow Counting,Crowd Density Monitoring) & Video Metadata & Traffic Monitoring |
| Smart by NVR | Smart Intrusion Prevention (SIP) & Behavior Analysis & (At same channel, only one smart function by NVR can be enabled simultaneously.) |
| VCA Search | Motor Vehicle Search & Non-Motor Vehicle Search & General Search & People Counting Report |
| Smart by IPC | Total 64-ch(Vehicle Detection,Temperature Detection,SIP,UMD,Video Metadata,Traffic Monitoring) |
| Search by Image | Support |
| Vehicle Picture Library | Up to 5 vehicle picture libraries,with up to 25,000 vehicle pictures in total |
| SIP by NVR | NVR824-128-R-IX-8G:64-ch NVR824-256-R-IX-16G:128-ch |
| UMD by NVR | NVR824-128-R-IX-8G:64-ch NVR824-256-R-IX-16G:128-ch |
| Behavior Analysis with normal cameras | NVR824-128-R-IX-8G:64-ch NVR824-256-R-IX-16G:128-ch |
| Behavior Analysis Type | No Work Clothes Detection & Smoking Detection & Smoke and Fire Detection & Calling Detection & Rat Detection & Long Stay Detection & Fall Detection & Fight Detection & Absence Detection & Climbing Detection & Sleep on Duty Detection & People Counting & Heat Map |
| Alarm | Description |
| General Alarm | Defocus Detection & Scene Change Detection & Object Left Behind & Object Removed & Auto Tracking & Motion Detection & Tampering & Video Loss Alarm Input & Audio Detection |
| Alert Alarm | IP Conflict & Network Disconnected & Disk Offline & Disk Abnormal & Illegal Access & Hard Disk Space Low & Hard Disk Full & Recording/Snapshot Abnormal & High CPU Temperature & High Motherboard Temperature & Array Damaged & Array Degraded |
| Hard Disk | Description |
| SATA | 24 SATA interfaces |
| Capacity | Up to 16TB for each disk(The maximum HDD capacity varies with environment temperature) |
| Disk Group | Support |
| Redundant Storage | Support |
| Disk Array Type | RAID 0,1,5,6,10,50,60 |
| External Interface | Description |
| Network Interface | 4 RJ45 10M/100M/1000M self-adaptive Ethernet Interface |
| USB | Front panel: 2 x USB2.0 & Rear panel: 2 x USB3.0 |
| RS485 | 1 |
| RS232 | 1 |
| Alarm In | 24-ch |
| Alarm Out | 8-ch |
| eSATA | 1 |
| miniSAS | 2 |
| Power Output | 12V |
| Power Supply | AC 100～240V |
| Power Switch | Support |
| Redundant Power Supply | Support |
| Working Environment | Description |
| Working Temperature | -10°C ~ + 50°C (+14°F ~ +122°F) |
| Working Humidity | ≤ 90% RH (non-condensing) |
| Power Consumption (without HDD) | ≤ 300W |
| Dimensions | Description |
| Weight (without HDD) | ≤ 12.5Kg (27.56lb) |
| Height | 4U |
| Dimensions | 484.6mm × 533mm × 175.5mm (19.1"×21.0"×6.9") |
| Certification | Description |
| Certification | CE, FCC, UL, RoHS, WEEE |
| CE | EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035 |
| FCC | Part15 Subpart B |
