Supports multiple device models including ADU8606, ADU8609, ADU8612, ADU8615, ADU8618, ADU8612-E, DC-B204, DC-B206, and DC-B209.
Supports Uniview and other manufacturers' IPC and NVR.
Live view, sequence display, and play signal source on video wall, open windows by one click, split window, window roaming, virtual LED, scenes and scene plans.
Supports small pixel pitch LED, turn on/off Uniview screens automatically at a set time, turn on/off manually or with a delay.
|Note: Functions available may vary with the server.|
|Device management||Add, edit, and delete devices on LAN|
Supports automatic search, and allows user to add devices manually
|Open device's Web interface from the client|
|View device status, including status of NVR-connected IPCs|
|Video wall||Add, edit, and delete video walls; supports small pixel pitch LED|
|Bind decoding channels automatically, bind decoding channels by one-click, splice screens, custom screen layout|
|Scene and scene plan (execute by set time interval or 24-hour schedule)|
|Multiple ways to open windows: one click (1/3/4/5/6/7/8/9/10/13/16/17/25/32/36/64 and M*N custom layout), right mouse button, or coordinates|
Window roaming and overlay, double-click window to view in full screen mode, renumber windows, window lock/unlock, display on top/bottom, and view window/split window info
|Start videos in batches on one or multiple screens|
|Sequence display videos in one or multiple windows|
|Play PC's video signals through server's DVI or VGA interface to the video wall.|
|Device group, including default group and custom group|
|Virtual LED: LED coordinates, custom LED content, font style, font size, font color, character spacing and alignment, background color and transparency, moving speed and mode; enable/disable virtual LEDs|
|Supports audio output and volume adjustment|
|Sequence resource||Add, edit, and delete sequence resource|
|Screen control||Turn on/off screen automatically at a set time|
Turn on/off screen manually
Turn on/off screen with delay
|Client configuration||Automatic login to EZWall|
Automatic login to Windows
Automatically display selected window on top
Play video with set or adaptive stream type
|Language||Chinese and English|
|OS and min. requirements||OS: 32-bit or 64-bit Microsoft Windows 7, 8, 10|
CPU: Intel Core i5 2.3GHz or higher
RAM: 4GB or higher
