Support Ultra 265/H.265/H.264 video formats
128/256-channel input
Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile C, Profile Q, Profile A, Profile T
Support 2-ch HDMI, 1-ch VGA, HDMI at up to 4K(3840x2160) resolution
HDMI1, HDMI2 and VGA independent outputs provided
Up to 12 Megapixels resolution recording
Redundant power supply optional
Support HDD hot swap with RAID 0, 1, 5, 6, 10, 50, 60 storage scheme configurable
24 SATA HDDs, up to 10TB for each HDD
Support 2 miniSAS Interfaces
Support 12V power output
ANR technology to enhance the storage reliability when the network is disconnected
Support cloud upgrade
Support N+1 Hot spare
Model | NVR824-128R | NVR824-256R |
Video/Audio Input | ||
IP Video Input | 128-ch | 256-ch |
Two-way Audio Input | 1-ch, RCA | |
Network | ||
Incoming Bandwidth | 768Mbps | |
Outgoing Bandwidth | 768Mbps | |
Remote Users | 128 | 256 |
Protocols | P2P, UPnP, NTP, DHCP, PPPoE | |
Video/Audio Output | ||
HDMI/VGA Output | VGA: 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz HDMI1/HDMI2: 4K (3840x2160)/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz | |
Recording Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | |
Audio Output | 1-ch, RCA | |
Synchronous Playback | 16-ch | |
Corridor Mode Screen | 3/4/5/7/9/10/12/16/32 | |
Decoding | ||
Decoding format | Ultra 265, H.265, H.264 | |
Live view/Playback | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | |
Capability | 5 x 4K@30, 20 x 1080P@30, 24 x 1080P@25, 40 x 960P@25, 45 x 720P@30, 54 x 720P@25, 96 x D1 | |
Hard Disk | ||
SATA | 24 SATA interfaces | |
Capacity | Up to 16TB for each HDD (The maximum HDD capacity varies with environment temperature) | |
Extension board | 4 | |
miniSAS* | 2 miniSAS ports | |
eSATA | 1 | |
Smart | ||
VCA Detection | Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Ultra Motion Detection(UMD) | |
VCA Search | Behavior Search, Vehicle Search | |
People Counting | People Flow Counting, Crowd Density Monitoring | |
Smart Intrusion Prevention (SIP), Vehicle Detection, UMD by Camera | Total 64-ch | |
Disk Array | ||
Array Type | RAID 0/1/5/6/10/50/60 | |
External Interface | ||
Network Interface | 4 RJ-45 10M/100M/1000M adaptive Ethernet Interface | |
Serial Interface | 1 x RS232, 1 x RS485 | |
USB Interface | Front panel: 2 x USB2.0, Rear panel: 2 x USB3.0 | |
Alarm In | 24-ch | |
Alarm Out | 8-ch | |
Power Output | 12V | |
General | ||
Power Supply | 100 ~ 240V AC Power Consumption: ≤ 70 W (without HDD) | |
Working Environment | -10°C ~ + 50°C (+14°F ~ +122°F), Humidity ≤ 90% RH (non-condensing) | |
Dimensions | 533mm ×484.6mm × 175.5mm (21.0 "×19.1" ×6.9") | |
Weight (without HDD) | ≤ 12.5 Kg (27.56 lb) |
