Support Ultra 265/H.265/H.264 video formats
4/8/16-channel input
Support mainstream cameras of ONVIF conformance(Profile S, Profile G, Profile T ) and RTSP protocols
Support 1-ch HDMI, 1-ch VGA, HDMI at up to 4K(3840x2160) resolution
HDMI and VGA simultaneous output
Up to 4K resolution recording
1 SATA HDD up to 8TB
Support cloud upgrade
Model | NVR301-04S3 | NVR301-08S3 | NVR301-16S3 |
Video/Audio Input | |||
IP Video Input | 4-ch | 8-ch | 16-ch |
Network | |||
Incoming Bandwidth | 64Mbps | ||
Outgoing Bandwidth | 48Mbps | ||
Remote Users | 128 | ||
Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SMTP, RTSP | ||
Video/Audio Output | |||
HDMI/VGA Output | HDMI: 3840x2160/30Hz, 1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz VGA: 1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz | ||
Recording Resolution | 4K/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | ||
Audio Output | 1-ch, 3.5mm | ||
Audio Compression | G.711A, G.711U | ||
Synchronous Playback | 4-ch | 8-ch | 16-ch |
Liveview display | 1/4 | 1/4/6/8/9 | 1/4/6/8/9/16 |
Corridor Mode Screen | 3/4 | 3/4/5/7/9 | 3/4/5/7/9/10/12/16 |
Snapshot | |||
FTP/Schedule/Event Snapshot | 1-ch snapshot, up to D1 resolution | ||
Decoding | |||
Decoding format | Ultra 265/H.265/H.264 | ||
Liveview/Playback | 4K/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | ||
Capability | 1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25, 4 x 1080p@30 | 1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25, 4 x 1080p@30, 8 x 720p@30 | 1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25, 4 x 1080p@30, 8 x 720p@30, 16 x D1@25 |
Hard Disk | |||
SATA | 1 SATA interface | ||
Capacity | Up to 8TB for each disk (The maximum HDD capacity varies with environment temperature) | ||
Smart | |||
VCA Detection by Camera | Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Audio Detection, Ultra Motion Detection(UMD) | ||
VCA Search | Face Search, Behavior Search | ||
Smart Intrusion Prevention (SIP), UMD by Camera | Total 4-ch | ||
General Alarm | |||
General Alarm | Motion, Tampering, Human Body Detection, Video Loss, Alarm Input | ||
Alert Alarm | IP Conflict, Network Disconnected, Disk Offline , Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal | ||
External Interface | |||
Network Interface | 1 RJ45 10M/100M self-adaptive Ethernet Interface | ||
USB Interface | Rear panel: 2 x USB2.0 | ||
RS232 | NA | ||
RS485 | NA | ||
Alarm In | NA | ||
Alarm Out | NA | ||
General | |||
Power Supply | 12V DC Power Consumption: ≤5 W (without HDD) | ||
Working Environment | -10°C ~ + 55°C (+14°F ~ +131°F), Humidity ≤ 90% RH (non-condensing) | ||
Dimensions (W×D×H) | 260mm × 240mm × 46mm (10.2"×9.4"×1.8 ") | ||
Weight (without HDD) | ≤0.98kg (2.16 lb) | ||
Certification | |||
Certification | CE, FCC, UL, RoHS, WEEE | ||
CE | EN 55032: 2015, EN 61000-3-3: 2013, EN IEC 61000-3-2: 2019, EN 55035: 2017 | ||
FCC | Part15 Subpart B, ANSI C63.4 |
