Support Ultra265/H.265/H.264 video formats
16/32-channel input
Support mainstream cameras of ONVIF conformance(Profile S, Profile G, Profile T ) and RTSP protocols
HDMI and VGA simultaneous output
Up to 8 Megapixels resolution recording
Accurate retrieval, instant playback
4 SATA HDDs, up to 8TB for each HDD
ANR technology to enhance the storage reliability when the network is disconnected
Support cloud upgrade
Model | NVR304-16S | NVR304-32S |
Video/Audio Input | ||
IP Video Input | 16-ch | 32-ch |
Two-way Audio Input | 1-ch, RCA | |
Network | ||
Incoming bandwidth | 160Mbps | |
Outgoing bandwidth | 64Mbps | 64Mbps |
Remote Users | 128 | |
Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP | |
Browser | IE(IE10/11) for Windows Firefox (version 52.0 and above) for Windows Chrome(version 45 and above) for Windows Edge(version 79 and above) for Windows | |
Video/Audio Output | ||
HDMI/VGA Output | HDMI: 4K (3840x2160) @30, 1920x1080p@60, 1920x1080p@50, 1600x1200@60, 1280x1024@60, 1280x720@60, 1024x768@60 VGA: 1920x1080p@60, 1920x1080p@50, 1280x1024@60, 1280x720@60, 1024x768@60 | |
Audio Output | 1-ch, RCA | |
Audio Compression | G.711A, G.711U | |
Recording Resolution | 8MP/5MP/4MP/3MP/1080p/960p/720p/960H/D1/2CIF/CIF | |
Synchronous Playback | 16ch | |
Liveview display | 1/4/6/8/9/16 | 1/4/6/8/9/16/25/36 |
Corridor Mode Screen | 3/4/5/7/9/10/12/16 | 3/4/5/7/9/10/12/16/32 |
Snapshot | ||
FTP/Schedule/Event Snapshot | 4-ch snapshot, up to D1 resolution | |
Decoding | ||
Decoding format | Ultra 265/H.265/H.264 | |
Live view/ Playback | 8MP/5MP/4MP/3MP/1080p/960p/960H/720p/D1/2CIF/CIF | |
Capability | 2 x 4K@30, 3 x 5MP@30, 4 x 4MP@30, 5 x 3MP@30, 8 x 1080p@30, 16 x 720p@30 | 2 x 4K@30, 3 x 5MP@30, 4 x 4MP@30, 5 x 3MP@30, 8 x 1080p@30, 16 x 720p@30,32 x D1 |
Hard Disk | ||
SATA | 4 SATA interfaces | |
Capacity | Up to 8TB for each disk (The maximum HDD capacity varies with environment temperature) | |
Smart | ||
VCA Detection by Camera | Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Ultra Motion Detection(UMD) | |
VCA Search | Behavior Search | |
People counting | People Flow Counting, Crowd Density Monitoring | |
Smart Intrusion Prevention (SIP), UMD by Camera | Total 8-ch | |
General Alarm | ||
General Alarm | Motion, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection | |
Alert Alarm | IP Conflict, Network Disconnected, Disk Offline , Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal | |
External Interface | ||
Network Interface | 2 RJ-45 10M/100M/1000M self-adaptive Ethernet Interfaces | |
USB Interface | Rear panel: 1 x USB2.0, 1 x USB3.0 Front panel: 1 x USB2.0 | |
RS232 | NA | |
RS485 | NA | |
Alarm In | NA | |
Alarm Out | NA | |
General | ||
Power Supply | 12V DC Power Consumption: ≤ 15W( without HDD ) | |
Working Environment | -10°C ~ + 55°C (+14°F ~ +131°F), Humidity ≤ 90% RH(non-condensing) | |
Dimensions (W×D×H) | 440mm × 344mm ×50mm (17.3" × 13.5" ×2.0") | |
Weight (without HDD) | ≤ 3.15 Kg (6.94 lb) | |
Certification | ||
Certification | CE, FCC, UL, RoHS, WEEE | |
CE | EN 55032: 2015, EN 61000-3-3: 2013, EN IEC 61000-3-2: 2019, EN 55035: 2017 | |
FCC | Part15 Subpart B, ANSI C63.4 |
